Unicel FG-1005 Replacement Filter for Hayward DEX6000MAN

Overview

The Unicel FG-1005 is a DE filter manifold assembly engineered as a direct replacement for Hayward DEX6000MAN-series grid systems, serving as the central collector hub for full-grid DE filter sets. The manifold incorporates molded ABS construction with integrated sector ports machined to OEM dimensional tolerances, ensuring leak-free seating of all grid sectors against the manifold face. The component is rated for continuous service at operating pressures up to 50 PSI and water temperatures to 104°F, consistent with residential and light commercial DE filter housing specifications. Port geometry, sector-to-manifold alignment, and standpipe interface are held to ±0.030 inch tolerance against OEM specifications, eliminating the bypass and DE blowback failure modes commonly associated with mismatched aftermarket manifolds.

Service interval: inspect the manifold at each DE recharge cycle (post-backwash) for hairline cracks, port seat wear, or sector seal degradation; replace immediately upon evidence of DE blowback into pool return, which typically manifests as ΔP failure to rise normally during DE charging or visible DE discharge at return fittings. Full annual disassembly is recommended for inspection of all manifold surfaces, O-ring seats, and sector port geometry. Chemical compatibility: ABS construction tolerates continuous service at standard pool chlorine levels with no upper ppm restriction, is compatible with muriatic acid soak at 1:20 dilution for calcium scale removal, and is fully compatible with enzyme-based filter cleaners. Avoid prolonged exposure to undiluted acid or solvent-based cleaners, which will compromise ABS molecular integrity. Standard Unicel 90-day manufacturing defect warranty applies through authorized distribution.

What's Included

Your order includes the selected quantity of DE filter grid sets. Each unit is individually inspected for quality before shipping.
