Unicel FG-1004 Replacement Filter for Hayward DEX4800MAN

Overview

The Unicel FG-1004 is a complete DE filter grid manifold assembly engineered as a direct replacement for the Hayward DEX4800MAN service component, supplying the central collection hub that ties individual grid sectors into the filter outlet standpipe. The manifold is molded from glass-reinforced polypropylene for chemical resistance and dimensional stability under sustained pressure cycling, with integrated grid ports machined to accept standard DE sector necks without adapter hardware. Designed for ProGrid, Micro-Clear, and equivalent grid-style DE filter housings, the FG-1004 maintains internal flow geometry consistent with OEM specifications to prevent flow imbalance across the grid set. Operating pressure range: 8–30 PSI residential; continuous service rating to 50 PSI. Constructed for compatibility with full DE grid arrays in standard 48 sq ft housing configurations.

Manifold service is typically performed concurrent with full grid set inspection on an annual disassembly cycle, or whenever DE blowback into the pool indicates grid-to-manifold seal failure or manifold cracking. Replacement triggers: visible stress cracks at port collars, warpage preventing flush grid seating, or persistent DE bleed-through after grid replacement. Installation requires full filter teardown — release internal pressure, remove top closure, lift grid assembly, and transfer sectors to the new manifold maintaining original orientation. Inspect and replace standpipe O-ring at the same service event; verify post-installation pressure against clean baseline and confirm no DE return through return inlets after recharge. Chemical compatibility: polypropylene construction tolerates continuous service at standard chlorine and bromine concentrations and is compatible with muriatic acid grid cleaning (1:20 dilution) and enzyme degreasers without restriction. Standard Unicel 90-day manufacturing defect warranty applies through authorized distribution.

What's Included

Your order includes the selected quantity of DE filter grid sets. Each unit is individually inspected for quality before shipping.
